Modified Equinoctial

The Modified Equinoctial Orbital Elements provide a set of parameters that describe an object's orbit without the singularities that arise in Keplerian elements (e.g., near-circular or equatorial orbits). These elements are particularly useful in numerical orbit propagation and optimization because they remain well-defined for nearly all types of orbits (with the exception of retro-grade orbits). They are an alternative to classical orbital elements, offering advantages in continuous, high-precision computations, especially when dealing with low-eccentricity orbits.

This library provides two variants of Modified Equinoctial coordinates:

• ModEq: Uses semi-parameter (p) as the size parameter
• ModEqN: Uses mean motion (η) as the size parameter instead of semi-parameter

Modified Equinoctial Orbital Element Frame [1]

Components

ModEq (Semi-Parameter Variant)

The ModEq coordinate type uses semi-parameter and consists of six elements:

• Orbital Shape and Size

  • semi-latus rectum (p): A measure of the orbit's size, similar to the semi-major axis, but defined as p=a*(1-e^2). It ensures well-defined behavior even for highly elliptical or circular orbits.
  • first component of eccentricity (f): First of two parameters that replace the scalar eccentricity. f=e*cos(ω + Ω) These components prevent singularities when the eccentricity is zero
  • second component of eccentricity (g): Second of two parameters that replace the scalar eccentricity. g=e*sin(ω + Ω)

• Orbital Orientation

  • first component of inclination (h): First of two parameters that replace the scalar inclination. h=tan(i/2)*cos(Ω) These components ensures the elements remain well-defined for equatorial orbits
  • second component of inclination (k): Second of two parameters that replace the scalar inclination. h=tan(i/2)*sin(Ω)

• Position within the Orbit

  • longitude of periapsis (L): This replaces true anomaly and combines information about the satellite's position within the orbit. L=ω + Ω + f

ModEqN (Mean Motion Variant)

The ModEqN coordinate type uses mean motion instead of semi-parameter:

• Orbital Shape and Size

  • mean motion (η): The angular rate of motion for a circular orbit with the same period, defined as η = √(μ/a³). This provides a direct measure of orbital period.
  • first component of eccentricity (f): Same as ModEq - f=e*cos(ω + Ω)
  • second component of eccentricity (g): Same as ModEq - g=e*sin(ω + Ω)

• Orbital Orientation

  • first component of inclination (h): Same as ModEq - h=tan(i/2)*cos(Ω)
  • second component of inclination (k): Same as ModEq - h=tan(i/2)*sin(Ω)

• Position within the Orbit

  • longitude of periapsis (L): Same as ModEq - L=ω + Ω + f

References

[1]: https://degenerateconic.com/modified-equinoctial-elements.html [2]: https://link.springer.com/article/10.1007/BF01227493 [3]: https://spsweb.fltops.jpl.nasa.gov/portaldataops/mpg/MPG_Docs/Source%20Docs/EquinoctalElements-modified.pdf
